Our AL143 2×3 spot light is ideal for medium working distances and comes available in a variety of wavelengths.

The AL143, 2×3 Spot Light is available in a wide range of wavelengths with multiple lens options.

Ideal Illumination for medium working distances.

Convenient mounting with an M4 nut channel.

Washdown version is available

PCN No: 144

Date Issued: February 22, 2018

Notice Type: Product Change

Type: Washdown Lights

Change Notification Summary

Advanced illumination (Ai) is improving the way we manufacture washdown lights which will change their outward appearance. We will be replacing the black cordstock with clear flowable silicon. This change will provide a more durable finish and will effect the following lights: AL116, AL126, AL143, AL179, AL295, BL128, QM116, QM126, LL174 and SL147.

Please contact your Ai Sales Representative if you have any questions.

Washdown Lights Flowable Silicon



PCN No: 122

Date Issued: May 13, 2016

Notice Type: Product Revision Change

Product Type: AL143

Change Notification Summary

In an effort to improve our products, Advanced illumination (Ai) will update the LEDs used in the AL143 design. This change will result in a brighter, more uniform light at the same price*. Customers may still buy the current revision of this model until August 5th of 2016. After that time, orders for these products will be converted to their respective AL143 Revison A models.

This LED change will result in additional wavelengths being available: 365nm, 375nm, 385nm, 405nm, 455nm, 505nm, 660nm, 730nm, and 940nm. Additionally the white LED color temperture will be changing from 6100K to 5500K.

*Pricing for IR wavelengths (730nm, 850nm & 940nm) will be reduced to the same price as visible wavelengths, while UV wavelengths (365nm, 375nm, 385nm & 395nm) will increase from $605 to $750.

Orders for customized (dash numbers) versions of AL143 will be honored until December 1st of 2016. Ai will be actively working with customers for those products to simplify the transition.

Please contact your Ai Sales Representative if you have any questions.

PCN 122 AL143



Electrical Specifications
Color
24V Current
All Other Controls
365, 375, 385, 395, 405
0.36 A
0.36 A Max
455, 470, 505, 530, WHI
0.36 A
0.48 A Max
590, 625, 660, 730
0.36 A
0.46 A Max
850
0.36 A
0.51 A Max
940
0.36 A
0.32 A Max
Normal Operating Temperature
0 - 60°C
Weight
141.8g (5oz)
Standard Cable Information
Up to 2 meters (80") long - 105°C rated PVC jacket, foil shield with drain.
Photobiological Risk Factor
Exempt Applicable Wavelengths: 850, 940
Group 1 (Low-Risk) Applicable Wavelengths: 455, 470, 505, 530, 590, 625, 660, 730, WHI
Group 2 (Moderate-Risk) Applicable Wavelengths: 365, 375, 385, 395, 405
Compliance
CE, RoHS, IEC 62471
IP Rating
IP65 Sealed, IP50 Unsealed
Lumen Maintenance
L70 = 50,000 Hours
