BALA Bar Lights

AL150 Series

Providing a broad area of illumination with controlled fall off for machine vision applications.

Full Description

Designed for machine vision applications that require broad illumination over a wide area with controlled fall off.

This BALA (Broad Area Linear Array) bar light series is expandable in 1″ increments up to 82″.

Applications requiring an even wider area of illumination can utilize two BALA bar lights aligned in parallel, facing each other.

AL150 derivatives include AL4424 (4″), AL4554 (9″) and AL46120 (20″) (which represent legacy part numbers)

Change Notice

PCN No: 166

Date Issued: May 5, 2023
Notice Type: Product Change
Product Type: 660nm Wavelength on traditional 5mm Lights Discontinuation

Change Notification Summary

Advanced illumination (Ai) will be ending the manufacture of the 660nm color option on our classic aimed lights due to the LEDs being discontinued from the manufacturer. We expect to have six months of inventory to fulfill orders, after that we suggest purchasing the same light but with the 625nm wavelength.

Please contact your Ai Sales Representative if you have any questions.

PCN 166

General Specs

Electrical Specifications

Color

24V Current

All Other Controls

625, 660

0.10 A

0.04 A

395, 470, 520, WHI

0.08 A

0.06 A

880

0.09 A

0.03 A

Normal Operating Temperature

0 - 60°C

Weight

Varies by size

Standard Cable Information

2 m long -0/+150 mm (80" -0/+6") - 105°C RATED PVC JACKET, FOIL SHIELD WITH DRAIN.

Photobiological Risk Factor

EXEMPT APPLICABLE WAVELENGTHS: 880
GROUP 1 (LOW-RISK) APPLICABLE WAVELENGTHS: 470, 520, 625, 660, WHI
GROUP 2 (MODERATE-RISK) APPLICABLE WAVELENGTHS: 395

Compliance

CE, RoHS, IEC 62471

IP Rating

IP50

Lumen Maintenance

L70 = 50,000 Hours
