High Intensity Linear Backlights
BL138 Series
Our High Intensity Linear Backlights offer 510 kLux output, perfect for back-lit, line-scanning applications.
Available in pre-engineered sizes from 6” (152mm) to 96” (2438mm) in 6″ increments.
A 3″ (75mm) length option is also available. Available intensity control provides illuminance adjustability for every 6″ increment via a 0 – 10v input
Electrical Specifications
Color
24V Current
All Other Controls
850, RGB
0.64A per 6 inches
0.64A Max per 6 inches
625
0.64A per 6 inches
0.64A Max per 6 inches
455, 530, WHI
0.75A per 6 inches
0.75A Max per 6 inches
Normal Operating Temperature
0 - 60°C
Weight
Per 12" - 1211.1g (42.72oz)
Standard Cable Information
2 m long -0/+150 mm (80" -0/+6") - 105°C rated PVC jacket, foil shield with drain.
Photobiological Risk Factor
Exempt Applicable Wavelengths: 850
Group 1 (Low-Risk) Applicable Wavelengths: 455, 530, 625, RGB, WHI
Group 1 (Low-Risk) Applicable Wavelengths: 455, 530, 625, RGB, WHI
Compliance
CE, RoHS, IEC 62471
IP Rating
Unsealed - IP50
Lumen Maintenance
L70 = 50,000 Hours
