Coaxial Lights

Coaxial Lights provide a type of diffuse illumination, generated from an internal source.  The light is then deflected downward onto the imaging plane via a 50% beamsplitter, which also allows light from the object to be collected by the camera above.  Ideal for imaging highly reflective objects or where the area of inspection is obscured by shadows from its surroundings.  The result of this illumination type is to apply a sheet of light to the object from above and collect the result of how the light is reflected, scattered or absorbed.

x
DL225
High current rated LEDs
Range of sizes available
High performance
Wavelengths
365nm 375nm 385nm 395nm 455nm 470nm 530nm 590nm 625nm 850nm 940nm White
Intensity
18,000 Lux
Lead Time
2 Weeks
Light Conditioning
N/A
Learn More
x
SL162
High current rated LEDs
Fixed dimensions
Superior performance focused spot light 22 degrees
Wavelengths
365nm 375nm 385nm 395nm 455nm 470nm 505nm 530nm 590nm 625nm 660nm 730nm 850nm 940nm White
Intensity
33,000 Lux
Lead Time
In Stock
Light Conditioning
N/A
Learn More
