The compact design of the DL2230 is easy to integrate into machine vision applications that require a space saving lighting design.

The housing of this Extra Small Dome Light has an outer dimension of 2.83” (71.9mm) and an inner, working diameter of 1.95” (49.5mm).

The compact design of the DL2230 is easy to integrate into machine vision applications that require a space saving lighting design.

The housing of this Extra Small Dome Light has an outer dimension of 2.83” (71.9mm) and an inner, working diameter of 1.95” (49.5mm).

Electrical Specifications
Color
24V Current
All Other Controls
625, 660, 880
0.15A
0.075A Max
395, 470, 520, WHI
0.10A
0.05A Max
Normal Operating Temperature
0 - 60°C
Weight
364.7g (12.9oz)
Standard Cable Information
2 m long -0/+150 mm (80" -0/+6") - 105°C rated PVC jacket, foil shield with drain.
Photobiological Risk Factor
Exempt Applicable Wavelengths: 880
Group 1 (Low-Risk) Applicable Wavelengths: 470, 520, 625, WHI
Group 2 (Moderate-Risk) Applicable Wavelengths: 395
Compliance
CE, RoHS, IEC 62471
IP Rating
Not Rated
Lumen Maintenance
L70 = 50,000 Hours
