UltraSeal Backlights

BL245 Series

Built for extreme environments, our IP69K certified lights are specifically engineered to withstand everything from prolonged liquid immersion to high-pressure steam cleaning and corrosive washdown solutions.

Built for extreme environments, our IP69K certified lights are specifically engineered to withstand everything from prolonged liquid immersion to high-pressure steam cleaning.

Crevice-free design with smooth-bodied surfaces to diminish the chance of material buildup while improving its ease of cleaning.

Proprietary nickel finish for vastly improved corrosion protection and engineered with thermal management in mind – housing is 11X more thermally conductive than stainless steel.

PCN No: 152

Date Issued: June 15, 2020

Notice Type: Product Revision Change

Product Type: BLXXYY, CBXXYY, FDXXYY, BL128, BL193, BL245

Change Notification Summary

In an effort to improve our products, Advanced illumination (Ai) will be updating the internal drivers and white LEDs used in the BLXXYY, CBXXYY, FDXXYY, BL128, BL193, and BL245. This change will result in white lights seeing a brightness increase of roughly 70% while maintaining equal pricing for small configurations and reduced pricing for large configurations. Excluding the BL128, 24V configured units will experience a current draw shift from 20mA to 30mA per sq. inch for 470nm, 520nm and white units while controller configured units will see a current draw shift from 15mA to 18mA per sq. inch for the same color configurations. Color temperatures will remain unchanged.

The LED upgrade and internal driver update for white color configurations will take place September 15th. The internal driver updates will occur November 9th for 470nm and January 7th for 520nm.

Please contact your Ai Sales Representative if you have any questions.

PCN 152

PCN No: 169

Date Issued: March 16, 2023

Notice Type: LED Update & New Housing Options

Product Type: BL245

Change Notification Summary

In an effort to improve our products, Advanced illumination (Ai) will update the LEDs used in the BL245 design. This change will result in a light 2-3x brighter at the same price. The conversion will begin on May 1st, 2023. In addition Ai will be adding stainless steel as a housing material choice for those applications that require it. This material will be stocked initially in the following sizes, 4x4, 6x6 and 8x4. Other sizes will be made to order with a 6-8 wks lead time. All part numbers moving forward with include the housing material in the PN. This LED change will result in slightly different wavelengths being available: 470nm, 530nm, 625nm, 850nm and White. Orders for customized (dash numbers) versions of BL245 will be honored until August 1st of 2023. Ai will be actively working with customers for those products to simplify the transition.

Please contact your Ai Sales Representative if you have any questions.

PCN 169

Electrical Specifications
Color
24V Current
All Other Controls
470, 520, 660, 880, WHI
0.03A per sq. inch
0.018A Max per sq. inch
Normal Operating Temperature
0-60°C
Weight
4" x 8" unit - 635g (22.4oz)
Standard Cable Information
2 M long -0/+150 mm (80" -0/+6") - 105°C rated PVC jacket, foil shield with drain.
Photobiological Risk Factor
Exempt Applicable Wavelengths: 880
Group 1 (Low Risk) Applicable Wavelengths: 470, 520, 660, WHI
Compliance
CE, RoHS, IEC 62471
IP Rating
IP69K Certified
Lumen Maintenance
L70 = 50,000 Hours
