UltraSeal Bar Lights

AL247 Series

Built for extreme environments, our IP69K certified lights are specifically engineered to withstand everything from prolonged liquid immersion to high-pressure steam cleaning and corrosive washdown solutions.

UltraSeal Bar Lights are ideal for hygienic inspection environments, aseptic manufacturing, and food and beverage applications.

UltraSeal Bar Lights are ideal for hygienic inspection environments, aseptic manufacturing, and food and beverage applications.  They are IP69K certified to withstand the harshest environments.

These Bar Lights feature either stainless steel or nickel plated aluminum housings depending on your washdown requirements.

Electrical Specifications
Color
24V Current
All Other Controls
455, 470, 505, 530, WHI
0.37A per 6 inches
0.35A Max per 6 inches
590, 625, 660, 730
0.38A per 6 inches
0.30A Max per 6 inches
850, 940
0.38A per 6 inches
0.20A Max per 6 inches
Normal Operating Temperature
0-60 deg C
Weight
11.2oz (317.5g) per 6 inches
Standard Cable Information
2 M long -0/+150 mm (80" -0/+6") - 105°C rated PVC jacket, foil shield with drain
Photobiological Risk Factor
Exempt Applicable Wavelengths: 850, 940
Group 1 (Low-Risk) Applicable Wavelengths: 455, 470, 505, 530, 590, 625, 666, 730, WHI
Compliance
CE, RoHS, IEC 62471
IP Rating
IP69K
Lumen Maintenance
L70 = 50,000 Hours
