Our MicroBrite™ Edge-lit backlights provides one of the highest flux densities of any compact backlight in our portfolio.
MicroBrite™ Backlights
BT Series
Part of the MicroBrite™ family of high performance, compact machine vision lights.
The edge-lit design provides one of the highest flux densities of any compact backlight in our portfolio.
Ultra-thin profile for installations with demanding space limitations.
Available in 3 sizes with a multitude of available wavelengths.
Base Model numbers include BT050050, BT200100, BT100100
Electrical Specifications
Part Number
Color
All Controls
BT050050
625
0.13A Max
BT050050
455, 530, WHI
0.18A Max
BT050050
850
0.075A Max
BT100100
625
0.32A Max
BT100100
455, 530, WHI
0.44A Max
BT100100
850
0.45A Max
BT200100
625
0.67A Max
BT200100
455, 530, WHI
0.92A Max
BT200100
850
0.45A Max
Normal Operating Temperature
0 - 60°
Weight
BT050050 - 54.43g (1.92oz)
BT100100 - 195.04g (6.88oz)
BT200100 - 313.00g (11.04oz)
BT100100 - 195.04g (6.88oz)
BT200100 - 313.00g (11.04oz)
Standard Cable Information
2 m long -0/+150 mm (80" -0/+6") - 105°C rated PVC jacket, foil shield with drain.
Photobiological Risk Factor
Exempt Applicable Wavelengths: 850
Group 1 (Low-Risk) Applicable Wavelengths: 455, 530, 625
Group 1 (Low-Risk) Applicable Wavelengths: 455, 530, 625
Compliance
CE, RoHS, IEC 62471
IP Rating
IP50
Lumen Maintenance
L70 = 50,000 Hours
