Edge-lit Flat Diffuse Lights provide a space saving design for the illumination of highly reflective objects.
Contained within a thinner housing than our Back-lit Flat Diffuse Lights (FD Series)
Edge-lit Flat Diffuse Lights
FX Series
Edge-lit Flat Diffuse Lights provide a space saving design for the illumination of highly reflective objects.
Custom aperture diameters are available from ¼” to 3” (6.4 to 76mm) in ¼” increments.
Contained within a thinner housing than our Back-lit Flat Diffuse Lights (FD Series)
Available in visible and infrared wavelengths.
Provides light intensities of up to 9.2kLux at 4” (102mm) standoff.
Pre-engineered, expandable sizes are available from 3”x 3” (76mm) to 24”x 24” (610mm) in 1” (25mm) increments.
This series comes with LB111 Mounting Brackets.
PCN No: 165
Date Issued: March 18, 2022
Notice Type: Optical Component Update
Product Type: BL, CB and FX
Change Notification Summary
In an effort to improve our products, Advanced illumination (Ai) has upgraded the optical components on the BX, CX, and FX Series. This upgrade only applies to size configurations less than or equal to 8" in non-illuminated length, otherwise known as the power side of the unit. This change will result in a brightness increase of roughly 40% over the previous revision. Pricing for each unit will remain the same. This change has gone into effect on BX, CX, and FX lights with serial numbers greater than 22060XXXX.
Please contact your Ai Sales Representative if you have any questions.
Electrical Specifications
Color
24V Current
All Other Controls
625
N/A
0.062 A Max per Linear Inch
455, 530, WHI
N/A
0.103 A Max per Linear Inch
850
N/A
0.05 A Max per Linear Inch
Normal Operating Temperature
0 - 60°C
Weight
4" X 4" unit = 553.4g (19.52oz)
Standard Cable Information
2 m long -0/+150 mm (80" -0/+6") - 105°C rated PVC jacket, foil shield with drain.
Photobiological Risk Factor
Exempt Applicable Wavelengths: 850
Group 1 (Low Risk) Applicable Wavelengths: 455, 530, 625, WHI
Group 1 (Low Risk) Applicable Wavelengths: 455, 530, 625, WHI
Compliance
CE, RoHS, IEC 62471
IP Rating
IP50
Lumen Maintenance
L70 = 50,000 Hours
CAD Files
- FXXXYY 03YY-08YY EASM (ZIP)
- FXXXYY 09YY-13YY EASM (ZIP)
- FXXXYY 14YY-18YY EASM (ZIP)
- FXXXYY 19YY-24YY EASM (ZIP)
- FX0404 STEP (ZIP)
- FX0808 STEP (ZIP)
- LB111 Mounting Bracket (ZIP)
