Oblique Line Lights

LL158 Series

The LL158 Series produces an oblique (30°) line of illumination for line scan applications in a passively cooled design.

When oriented across a moving web or conveyor line, unlike standard line lights, this linear light’s unique geometry highlights engraved or raised lines that run parallel to the material travel.

The LL158 Series produces an oblique (30°) line of illumination for line scan applications in a passively cooled design.

When oriented across a moving web or conveyor line, unlike standard line lights, this linear light’s unique geometry highlights engraved or raised lines that run parallel to the material travel.

Provides an intensity level of 53kLux (working distance of 75mm).

Pre-engineered for expandability in 6” (152mm) increments up to 90” (2.28m).

Available intensity control provides illuminance adjustability for every 6″ increment via a 0 – 10v input.

Electrical Specifications
Color
24V Current
All Other Controls
625
0.70 A per 6"
0.70 A Max per 6"
470, 530, WHI
0.76 A per 6"
0.76 A Max per 6"
Normal Operating Temperature
0 - 60°C
Weight
1211.1g (42.72oz) Per 12"
Standard Cable Information
Up to 2 meters (80") long - 105°C rated jacket, foil shield with drain.
Photobiological Risk Factor
Group 1 (Low Risk) Applicable Wavelengths: 470, 530, 625, WHI
Compliance
CE, RoHS, IEC 62471
IP Rating
IP50
Lumen Maintenance
L70 = 50,000 Hours
